Specification

Basic Construction
Mode 24awg 22awg 20awg 18awg 16awg 14awg 12awg 10awg
2c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 3.89 4.12 4.5 4.99 5.45 6.23 6.99 8.28
3c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 4.47 4.76 5.24 5.85 6.43 7.4 8.36 9.97
4c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 4.95 5.29 5.85 6.56 7.23 8.38 9.49 11.37
5c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 5.37 5.75 6.38 7.19 7.94 9.23 10.48 12.6
6c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 5.75 6.17 7.26 8.15 8.98 10.59 11.97 14.3
7c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 6.1 6.55 7.7 8.66 9.56 11.29 12.79 15.31
8c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 6.42 6.9 8.11 9.14 10.1 11.94 13.55 16.25
9c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 6.72 7.24 8.49 9.58 10.61 12.55 14.26 17.13
10c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 7.01 7.55 8.85 10 11.09 13.12 14.93 17.96
11c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 7.28 7.85 9.19 10.4 11.54 13.67 15.56 18.74
12c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 7.54 8.13 9.52 10.79 11.97 14.19 16.17 19.5
13c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 7.78 8.4 9.83 11.15 12.39 14.69 16.75 20.22
14c Dielectric o.d 1.5 1.65 1.9 2.22 2.52 3.03 3.53 4.37
Jacket o.d 8.02 8.66 10.14 11.51 12.79 15.17 17.31 20.91
