Specification

Temperature Range
Transport/Storage Temp Installation Temp Operation Temp
-40℃~+70℃ -30℃~+50℃ -40℃~+70℃


Structural Characteristic
Fiber Count 2~288
Loose Tube Colored Fiber In Pbt Loose Tube, Filled With Fiber Gel
Central Strength Member Steel Wire Or Frp(Fiber Reinforce Plastic Rod)
Waterproof Layer Cable Core Filled With Cable Gel Or Water Blocking Tape, Water Blocking Yarns
Corrugated Steel-Plastic Tape Ensures Nice Moisture Proof And Side Pressure Resisting Capability Of Cable.
Sheath Polyethylene(PE)


Technical Data(Gyfts)
Fiber Count Cable Outer Dia (Mm) Cable Weight (Kg/Km) Min.Bending Radius(Mm) Permissible Tensile Force(n) Permissible Pressure Force(n/100mm)
Static Dynamic Short Term Long Term Short Term Long Term
2-36 10.5 107 10d 20d 1500 600 1000 300
38-72 11.2 125 10d 20d 1500 600 1000 300
74-84 11.9 138 10d 20d 1500 600 1000 300
86-96 12.5 155 10d 20d 1500 600 1000 300
98-108 13.2 172 10d 20d 1500 600 1000 300
132-144 15.3 220 10d 20d 1500 600 1000 300
288 18.3 335 10d 20d 1500 600 1000 300
Note:"d" Is Cable Diameter
