Specification

Cable Construction(CAT5e)
Center Conductor 0.51mm Copper*2*4 Pairs
Dielectric 0.91mmPE
Shield PET+Al Foil
Jacket LSZH
Nom.Thick 0.55mm
Nom.Od(Mm) 6.9mm
Cable Marking According Client's Of Request


Electrical Characteristics
Frequency(Mhz) Attenuation(Db/100m) Return Loss (Db/100m) Pair To Pair
Next(Db/100m) Elfext(Db/100m)
1 2.00 20.00 68.30 66.80
4 4.00 23.00 59.30 54.70
8 5.80 24.50 54.30 48.70
10 6.50 25.00 53.30 46.80
16 8.20 25.00 50.30 42.90
25 10.40 24.30 47.30 38.80
31.25 11.70 23.60 45.90 36.90
62.5 17.00 21.50 41.40 30.80
100 22.00 20.10 38.30 26.80
200 32.40 18.00 33.80 20.70
