VATC cable refers to a type of high-performance cable typically used in environments where extreme protection, especially against mechanical damage, is necessary. Cables with an inner conductor surrounded by additional layers of protection are designed for specific applications that require both electrical conductivity and durability under harsh conditions. These cables are commonly used in industries such as telecommunications, aerospace, military, and industrial systems where reliability is critical.

Key Features of VATC Cable with an Inner Conductor Surrounded:

Inner Conductor:

The inner conductor in VATC cables typically consists of a solid or stranded metal core (usually copper or aluminum) that carries the electrical signal or power. Copper is the most common choice for its excellent conductivity.

Surrounding Layers:

• The inner conductor is surrounded by a series of insulating, shielding, and protective layers to enhance the performance of the cable in different environments.
• Insulation Layer: The conductor is typically surrounded by a layer of insulation material, such as polyethylene (PE), polyvinyl chloride (PVC), or cross-linked polyethylene (XLPE), to prevent electrical shorting, leakage, or interference from surrounding components.
• Shielding: VATC cables often include one or more shielding layers, such as braided metal wires (usually tinned copper or aluminum), foil shields, or a combination of both.
• Armor or Armoring Layer: In VATC cables, the shielding is often followed by a mechanical protection layer made of steel, aluminum, or other rugged materials. The armor provides additional protection against abrasion, impact, crushing, or other physical damage, making the cable more robust for outdoor or industrial use.

Outer Jacket:

• The outermost layer of the VATC cable is typically a durable outer jacket designed to protect the inner layers from environmental elements, such as UV radiation, moisture, oils, and chemicals.
• Materials for outer jackets might include PVC, LSZH (Low Smoke Zero Halogen), or thermoplastic elastomers (TPE), depending on the specific environmental requirements (e.g., flame resistance, flexibility).

Applications of VATC Cable:

• Telecommunications: Used for high-speed data transmission in environments requiring high durability, such as underground installations or outdoor settings.
• Military and Aerospace: Used in critical communication systems, where ruggedness and protection against interference are crucial.
• Industrial Systems: Used for industrial machinery and systems that need reliable performance in harsh environments with mechanical stress.
• Automotive: For automotive wiring systems that require both flexibility and protection from heat and mechanical wear.
• Oil and Gas: Often used in petrochemical industries for instrumentation and control applications in harsh environments where cables are exposed to chemicals, high temperatures, or pressure.

Key Considerations When Choosing VATC Cable:

1. Voltage Rating: Ensure that the insulation material can handle the required voltage level without breakdown or degradation.
2. Temperature Range: Verify that the cable’s insulation and jacket materials can withstand the expected temperature fluctuations in the intended environment.
3. Mechanical Protection: The degree of armoring or protection needed will depend on the specific environment (e.g., whether it will be exposed to heavy machinery, chemicals, or physical impacts).
4. Signal Integrity: If the application requires high-frequency transmission (such as for telecommunications), the shielding must be of high quality to minimize signal degradation or interference.

VATC cables with an inner conductor surrounded by insulating, shielding, and protective layers provide robust and reliable solutions for high-performance applications where environmental resilience and signal integrity are critical. The combination of excellent mechanical protection, electrical isolation, and effective shielding makes them suitable for a wide range of demanding industrial, military, telecommunications, and aerospace applications.
