Optical cables are mainly used in the transmission of optical signals in telecommunications networks

1. Package: wood drum

2. Certificate: CE ROHS ETL UL CPR

3. Free samples

4. Provide test report

5. Stable quality, complete testing equipment

Specification

Temperature Range

Transport/Storage Temp	Installation Temp	Operation Temp
-40℃~+70℃	-30℃~+50℃	-40℃~+70℃

Structural Characteristic

Fiber Counts	2~48
Loose Tube	Colored Fiber In Pbt Loose Tube, Filled With Fiber Gel
Armor	Single Fine Steel Wires Round The Loose Tube
Waterproof Layer	Cable Core Filled With Cable Gel Or Water Blocking Tape, Water Blocking Yarns
Sheath	Polyethylene(PE)

Technical Data

Fiber Count	Cable Outer Dia (Mm)	Cable Weight (Kg/Km)	Min.Bending Radius(Mm)		Permissible Tensile Force（n）		Permissible Pressure Force（n/100mm）
Fiber Count	Cable Outer Dia (Mm)	Cable Weight (Kg/Km)	Static	Dynamic	Short Term	Long Term	Short Term	Long Term
2-12	8.3	71	10d	20d	1500	600	1000	300
14-24	9.4	126	10d	20d	1500	600	1000	300
26-36	10.3	145	10d	20d	1500	600	1000	300
38-48	11.3	168	10d	20d	1500	600	1000	300
Note："d" Is Cable Diameter
